TOUCHSCREEN INTERFACE

The user-friendly graphic interface, together with the latest touchscreen technology on 22” widescreen monitor simplify and speedup all operations and program selection.



Fully Automa

No manual operations are required by the operator.

The minimized spin and diagnosis times make it one of the fastest on the market



TOUCHLESS SYSTEM FOR DIMENSION MEASUREMENT

“Combined” system, which includes an internal laser sensor and an external sonar sensor (TL3). The wheel balancer automatically measures the wheels without any intervention by the operator. All operations for the positioning of adhesive counterweights have been simplified.



Hidden Weight 2.0

New Hidden Weight 2.0 programme to divide the external side balancing adhesive weight into two equivalent weights hidden behind the spokes.A completely autonomous operation.



 AUTO POSITIONING

The wheel is braked and put in balancing position at the end of the spin (RPA).



 LED SPOTLIGHT

Integrated LED spotlight to light-up the work area and make it easier to clean the rim, and apply the counterweights..



SONAR RUNOUT

Diagnostic system with sonar RunOut Detector Kit to reduce the disturbances (vibrations) generated by wheel geometric deformations.

• In a single spin, it measures wheel radial runout and calculatesthe best coupling of the parts, thus solving the typical vibrations generated during road driving.

• Simplified troubleshooting indications for the operator.



 COUNTERWEIGHT APPLICATION

The internal point laser (LASER POINT SYSTEM) indicated adhesive counterweight

application position with the utmost accuracy



Automatic wheel clamp

New automatic electromechanical wheel clamping system for shorter times and higher centring accuracy



 EASY TYRE SET

A special vehicle tyre set diagnostic tool. Once all wheel data are stored, MT3900up C suggests their optimal positioning on the vehicle for maximum comfort and vehicle safety.

Only if equipped with SONAR RUNOUT Kit



 SPACE-SAVING wheel guard

Space-saving wheel guard designed to allow wheel balancer wall mounting as well holding wheels up to a maximum diameter of 44” (1,118 mm)





 Inclined front side

To improve the ergonomics and make the access to the inner part of the rim easier for the operator.



 MULTIFUNCTION BUTTON

It speeds up the different work programmes.



 EASY WEIGHT

The EASY WEIGHT programme suite including, among others, also the MINIMUM WEIGHT software, comes as standard. It allows reducing, also through the analysis of the different threshold values, the number of weights based on vehicle type: fast or slow (unique on the market).
